Icon Vehicle Dynamics
ICON K67100 7" Stage 1 Suspension System
ICON K67100 7" Stage 1 Suspension System
Regular price
$2,976.50 USD
Regular price
Sale price
$2,976.50 USD
Unit price
/
per
Couldn't load pickup availability
The Icon K67100 7" Stage 1 Suspension System from CDP for the 2005-2007 Ford F-250/350 6.0L Powerstroke 4WD offers unparalleled performance and ride quality while giving the vehicle clearance for 38" Tall tires. This system comes complete with Icon 2.0 Aluminum Series Shocks, Dual Rate Coil Springs, Drop Pitman Arm, Pan Rod Bracket, Brake Line Brackets, Radius Arm Drop Down Brackets, Icon's Fabricated 6" Blocks and U-bolts. All of these components (excluding shocks) are covered by Icon's Limited Lifetime Warranty.
Notes:
OEM Wheels & Tires Fitment: Yes
Recommended Aftermarket Wheels: Icon Alloys | 17x8.5" W/ 5.00" Backspace / 6mm Offset
Recommended Aftermarket Wheels: Icon Alloys | 18x9" W/ 5.25" Backspace / 6mm Offset
Recommended Aftermarket Wheels: Icon Alloys | 20x9" W/ 5.25" Backspace / 6mm Offset
Recommended Aftermarket Tires: 37" X 12.50" (Larger Tires May Fit But Fender Trimming And Modifications Will Be Required.)
Application Note #6: Springs Are Rated For Diesel Engines Only
Application Note #21: Not Applicable On Vehicles Equipped With A Manual Transmission
Application Note #28: Pinch Weld On '05-'10 Superduty Radius Arms May Come In Contact With Radius Arm Drop Bracket Hardware
Application Note #29: 7" Systems Using A 4-Link In Place Of The Factory Radius Arms Do Not Require The Use Of Alignment Cams. Caster Can Be Adjusted By The Lower Link Arms
Application Note #55: Shocks Are Fully Serviceable. Coilover Heights Indicated Are For A Stock Equipped Vehicle
Application Note #56: Rear Add-A-Leaf Required For Truck To Sit Level When Using 6" Block Included In Kit
Features:
- 75% Increase In Wheel Travel
- Less Body Roll Than Stock
- 7" More Travel From Ride Height To Front Bump Stops
- State Of The Art Dual-Rate Coil Spring
- Lifetime Guarantee That Coil Springs Won't Sag
- Clears 38" Tall Tires
- No Change In Towing Capacity
- No Drive Shaft Modifications Needed
- 100% Bolt-On System - No Drilling, Cutting, Or Welding Necessary
Notes:
OEM Wheels & Tires Fitment: Yes
Recommended Aftermarket Wheels: Icon Alloys | 17x8.5" W/ 5.00" Backspace / 6mm Offset
Recommended Aftermarket Wheels: Icon Alloys | 18x9" W/ 5.25" Backspace / 6mm Offset
Recommended Aftermarket Wheels: Icon Alloys | 20x9" W/ 5.25" Backspace / 6mm Offset
Recommended Aftermarket Tires: 37" X 12.50" (Larger Tires May Fit But Fender Trimming And Modifications Will Be Required.)
Application Note #6: Springs Are Rated For Diesel Engines Only
Application Note #21: Not Applicable On Vehicles Equipped With A Manual Transmission
Application Note #28: Pinch Weld On '05-'10 Superduty Radius Arms May Come In Contact With Radius Arm Drop Bracket Hardware
Application Note #29: 7" Systems Using A 4-Link In Place Of The Factory Radius Arms Do Not Require The Use Of Alignment Cams. Caster Can Be Adjusted By The Lower Link Arms
Application Note #55: Shocks Are Fully Serviceable. Coilover Heights Indicated Are For A Stock Equipped Vehicle
Application Note #56: Rear Add-A-Leaf Required For Truck To Sit Level When Using 6" Block Included In Kit
Note:
Installation Manuals:
I62530 Installation Manual
I64040 Installation Manual
I66514 Installation Manual
